Automatic Chemistry Analyzer Biossays 240plus
$27,700.00$29,500.00 (-6%)
1.High efficient washing station for cuvettes (Not available in Biossays 240)
2.Random access, continuous loading
3.Incorporated with liquid level sensor, volume tracking, collision detection and clot detection
4.24 hours refrigeration system with separate switch
5.Unlimited STAT position
6.Diffraction grating filter with 16 standard filters in the range 340nm-800nm
7.Automatic cuvette & water blank check
8.Real-time reagent levels monitoring, displaying and alerting function
9.Calibration options with 1-Point Linear、2-Point Linear、 Multi-Point Linear, Non-Linear, K Factor
Specifications
Features of Automatic Biochemistry Analyzer Biossays 240 Plus:
1.High efficient washing station for cuvettes (Not available in Biossays 240)
2.Random access, continuous loading
3.Incorporated with liquid level sensor, volume tracking, collision detection and clot detection
4.24 hours refrigeration system with separate switch
5.Unlimited STAT position
6.Diffraction grating filter with 16 standard filters in the range 340nm-800nm
7.Automatic cuvette & water blank check
8.Real-time reagent levels monitoring, displaying and alerting function
9.Calibration options with 1-Point Linear、2-Point Linear、 Multi-Point Linear, Non-Linear, K Factor
Specification of Automatic Biochemistry Analyzer Biossays 240 Plus:
Equipment type: Automatic discrete, unlimited STAT priority
Throughput: 240 tests/hour
ISE: Optional (200 tests/hour)
Measuring principle: 1-Point Endpoint、2-Point Endpoint 、2-Point Rate, Rate A、ISE technology
Sample type: Serum; Plasma; Urine; CSF
Sample volume: Biochemistry: 2.0 L-35.0 L; ISE: 90.0 L
Sample handling: up to 90 sample positions, continuous loading
Reagent handling: up to 90 reagent positions, continuous loading, 24 hours refrigeration function with separate switch
Reagent volume: 20ul-350ul
Reaction temperature: 37.0℃±0.2℃
Reagent bottle volume 10mL+30mL、50mL
Reagent time: 12 min/32 min
Wavelength: 16 wavelengths, 340nm, 380nm, 405nm,450nm, 480nm, 505nm, 546nm, 570nm, 600nm, 630nm, 660nm, 700nm, 720nm, 750nm, 780nm, 800nm
Dispensing system: Sample & reagent probe with liquid level detection and clot detection
Mixing system: 1 independent stirring needle （coated with TEFLON）
Dilution: auto-dilution
Power supply: a.c.100V-240V, 50/60H
Barcode type: code 128, code 39, code 93, codabr, 2/5 Interleaved
Reaction volume: 100ul-380ul
Cuvette: 80 optical plastic cuvettes, resumable, optical diameter is 5mm (Reaction cuvettes are disposable in Biossays 240)
Light source: 20 W/12V, halogen lamp, 2000 H
Absorbance range: 0 ABS-3.5 ABS
Water consumption: Biossays 240: Maximum 2.5 L/H (1.5 L/H; Single Reagent); Biossays 240 Plus: Maximum 3.0 L/H (2.0 L/H; Single Reagent)
Weight: Biossays240 plus: 68kg
Dimension L x W x H= 730mm x 500mm x 620mm (28.74in x 19.69in x 24.41in)
