Infrared Vein Finder NEU265
- Non-contact infrared technology for accurate vein visualization
- Effective positive projection distance of 29cm to 31cm
- Light projection intensity range: 300lux to 1000lux
- Operates with lithium-ion polymer batteries for portability
- Service voltage between 3.0V and 4.2V
- IPX0 rating; not waterproof, handle with care around liquids
- Recommended usage height and angle for best results
- Includes safety precautions for electromagnetic interference
- Store in a cool, dry place when not in use
- Lithium polymer battery precautions: do not dispose in fire or improperly
- SKU
- NEU265
- Brand
- MedGroup
- Availability
- In stock
- ✓ Warranty included
- ✓ Worldwide shipping
Infrared Vein Finder NEU265
Non-contact infrared technology for rapid, accurate subcutaneous vein visualization. Delivers real-time vein mapping with effective projection distances of 29–31 cm, enabling confident venipuncture and IV placement across diverse patient populations.
Clinical overview
The Infrared Vein Finder NEU265 employs non-contact infrared technology to visualize subcutaneous veins in real time, eliminating the need for palpation and reducing procedural anxiety. By projecting an infrared image directly onto the skin surface, clinicians gain immediate, accurate vein mapping—critical for first-pass success rates in venipuncture, peripheral IV placement, and phlebotomy across pediatric, geriatric, and difficult-access populations.
Operating at wavelengths of 750–980 nm, the device detects hemoglobin absorption patterns beneath the epidermis, rendering veins as dark lines against lighter surrounding tissue. With an effective projection distance of 29–31 cm and adjustable light intensity (300–1000 lux), the NEU265 adapts to varied clinical environments—from brightly lit emergency departments to dimly lit procedure rooms—ensuring consistent visualization quality and operator confidence.
Key features & surgeon benefits
Real-Time Vein Mapping
- Non-contact infrared projection eliminates procedural trauma
- 750–980 nm wavelength detects hemoglobin absorption patterns
- Immediate vein identification reduces procedure time
Cordless & Battery-Powered
- Lithium-ion polymer battery (3.0–4.2 V DC) enables bedside mobility
- Lightweight handheld design fits standard clinical workflows
- Rapid charge cycles support continuous clinical use
Variable Projection & Intensity
- Effective distance 29–31 cm accommodates diverse anatomies
- Light intensity range 300–1000 lux adjusts to ambient lighting
- Optimal positioning height and angle guidance included
Clinical-Grade Design
- IPX0 rating; non-waterproof—suitable for dry clinical environments
- Electromagnetic interference precautions documented
- No direct eye exposure during operation; safety protocols included
Technical specifications
| Indications | Vein visualization for venipuncture, IV access, phlebotomy, and vascular procedures |
|---|---|
| Effective projection distance | 29–31 cm |
| Light projection intensity | 300–1000 lux |
| Active radiation wavelength | 750–980 nm (infrared spectrum) |
| Electrical source | Lithium-ion polymer battery |
| Service voltage | DC 3.0–4.2 V |
| Liquid ingress protection | IPX0 (not waterproof) |
| Material | Medical-grade polymer housing |
| Packaging | Original protective case with charging cable and user manual |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Infrared Vein Finder | Handheld non-contact infrared projector with integrated battery | 1 |
| Lithium-ion polymer battery | Rechargeable 3.0–4.2 V DC power cell | 1 |
| USB charging cable | Standard micro-USB or proprietary connector for battery charging | 1 |
| User manual & safety guide | Clinical operation instructions and electromagnetic interference precautions | 1 |
| Protective carrying case | Padded storage case for transport and storage | 1 |
Get in touch for pricing & availability
Contact our clinical sales team to discuss pricing, volume discounts, and customization options for the Infrared Vein Finder NEU265. We offer rapid deployment and comprehensive post-sale support.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
