4D Full Digital Trolley Color Doppler Ultrasound NEUCU30
$19,770.00$24,990.00 (-21%)
– 4D Full Digital Trolley Color Doppler Ultrasound NEUCU30
– Supports multiple displaying modes: B, M, Doppler, and more
– Advanced full-digital signal processing for superior imaging
– Intelligent imaging technologies including THI and iBeam TM
– Extensive measurement packages for abdomen, OB, gynecological, urology, cardiac, and vascular assessments
– Adjustable parameters such as Doppler sound output, wall filter, and sampling frame
– High storage capacity with 500G available for images in BMP, JPEG, and PNG formats
– Standard configuration includes a 15-inch LED monitor and dual probes
– Optional accessories available for expanded functionality, including transvaginal probes and DICOM 3.0 compatibility.
4D Full Digital Trolley Color Doppler Ultrasound NEUCU30
Advanced Full-Digital Ultrasound System with Comprehensive Diagnostic Capabilities
Experience superior diagnostic imaging with the NEUCU30, a state-of-the-art 4D full digital trolley color Doppler ultrasound system. Featuring advanced full-digital signal processing, intelligent imaging technologies including THI and iBeam TM, and extensive measurement packages for abdomen, obstetrics, gynecological, urology, cardiac, and vascular assessments. With multiple displaying modes, adjustable parameters, and high storage capacity, this system delivers exceptional performance for comprehensive clinical examinations.
ISO Certified
FDA Approved
Medical Grade
24/7 Support
Advanced 4D Color Doppler Ultrasound Technology
The NEUCU30 represents the pinnacle of ultrasound diagnostic technology, combining full-digital beam forming with advanced signal processing capabilities. This comprehensive system delivers exceptional image quality through intelligent technologies such as THI tissue harmonic imaging, PSHI TM broadband multi-frequency harmonic imaging, and iBeam TM intelligent space image technology. With support for multiple displaying modes including B, M, PW, CFM, duplex, and triplex modes, the NEUCU30 provides unparalleled versatility for a wide range of clinical applications.
Designed for optimal workflow efficiency, the NEUCU30 features real-time dynamic focusing, dynamic aperture in all fields, and one-key optimization for instant image enhancement. The system includes extensive measurement packages tailored for specific diagnostic needs, from obstetrics and gynecology to cardiology and vascular studies. With a scanning depth of up to 300mm, 500G storage capacity, and support for multiple image formats, this system is engineered to meet the demanding requirements of modern medical imaging facilities.
Clinical Applications
Technical Specifications
| Parameter | Specification |
|---|---|
| Displaying Mode | B, B/B, 4B, B/M, M, PW, B/C, B/C/D, B/D, duplex, triplex, CFM |
| Signal Processing | Full-digital beam forming, dynamic filter, dynamic real time receiving focusing, RDA, DRA, spectral processing, CFM processing, real-time dynamic focusing, dynamic aperture in all fields |
| Image Processing Technologies | THI, PSHI TM broadband multi-frequency harmonic image, Speckle-reduction, Power adjustable, Smoothing function, iBeam TM intelligent space image technology, iZoom TM undistorted full screen image, Free Xros M, Engineer control technology with low power consumption, Edge enhancement, Image optimizing disposal, One-key optimization |
| Image Manipulation | Image conversion, Up/down conversion, Left/right conversion |
| Doppler Features | Sound output volume adjustable, Wall filter adjustable, Base line adjustable, Sampling frame adjustable, Spectrum sampling volume adjustable, Spectrum sampling volume angle adjustable, PRF adjustable |
| General Measurements | B mode: distance, circumference, area, volume, angle, area Red, Diam Red M mode: distance, time, velocity, heart rate |
| Abdomen Measurement | Liver, GB, Aorta, GBWT, CBD, Portal Vein, Spleen |
| OB Packages | EDD table: GS, BPD, CRL, FL, YS, TAD, LV, OFD, NT, AC, HC, APAD, Cxlength |
| Gynecological Packages | Uterine measurement (diameter, endometrial); left/right ovary measurement; left/right sacculus measurement; Cervix; Uterine depth |
| Urology Packages | Left/right kidney measurement, Volume, Cortex |
| Small Parts Measurement | Left/right thyroid, volume, Isthnus and calculating report |
| Cardiac Measurement Package | Heart rate, Valve speed, LV, aortic, mitral, ventricular |
| Skeletal & Muscles | Distance, area, Hip angle measurements |
| Vascular Measurements | Stenosis D, Stenosis A, Lt/Rt VVA, Lt/Rt Rulb, Lt/Rt ICA |
| Body Mark | Abdominal, Gynecology, Obstetrics, Small parts |
| Scanning Depth | Up to 300mm |
| Cine Loop | Automatically & manually, speed control |
| Image Storage Format | BMP, JPEG, PNG |
| Image Storage Size | 500G |
| Input/Output Ports | VGA, USB port, DICOM port (network port) |
| Monitor | 15 inch LED monitor (standard), 19 inch LED monitor (optional) |
| Standard Configuration | Main unit, 15 inch LED monitor, 3.5MHz convex probe, 7.5MHz linear probe, free arm, 4 probe connectors, user’s manual, 500G hard disk, DVD-RW |
| Optional Accessories | 6.5MHz transvaginal probe, 19 inch LED monitor, video printer, laser printer, DICOM 3.0, biopsy kit |
| Workstation System | Intelligent built-in workstation system (Chinese/English) |
Key Features
Full-Digital Beam Forming Technology
Advanced full-digital signal processing with real-time dynamic focusing and dynamic aperture in all fields ensures superior image quality and diagnostic accuracy across all imaging modes.
Tissue Harmonic Imaging (THI)
Enhanced tissue differentiation and improved image contrast through advanced harmonic imaging technology, reducing artifacts and providing clearer visualization of anatomical structures.
PSHI TM Broadband Multi-Frequency Harmonic Imaging
Proprietary broadband harmonic technology delivers exceptional penetration and resolution across multiple frequency ranges for optimized imaging of different tissue types and patient body habitus.
Speckle Reduction Technology
Intelligent speckle reduction algorithms enhance image clarity by minimizing noise while preserving critical diagnostic details, resulting in cleaner, more interpretable images.
iBeam TM Intelligent Space Image Technology
Proprietary spatial processing technology optimizes image quality by intelligently analyzing and enhancing three-dimensional acoustic data for superior visualization of complex anatomical structures.
iZoom TM Undistorted Full Screen Imaging
True magnification without pixelation or distortion, allowing clinicians to examine areas of interest in detail while maintaining image integrity and diagnostic confidence.
One-Key Optimization
Instant image enhancement with a single button press, automatically adjusting multiple parameters for optimal image quality and streamlining workflow efficiency.
Comprehensive Doppler Capabilities
Complete Doppler functionality including PW, color flow mapping, and spectral analysis with adjustable parameters for precise hemodynamic assessment and vascular evaluation.
Extensive Measurement Packages
Pre-configured measurement packages for obstetrics, gynecology, cardiology, urology, vascular studies, and more, with automatic calculations and standardized reporting.
Advanced Cine Loop Function
Automatic and manual cine loop recording with variable playback speed control for detailed review of dynamic events and retrospective analysis of cardiac cycles.
High-Capacity Storage System
500G internal storage with support for multiple image formats (BMP, JPEG, PNG) and DVD-RW capability for comprehensive data archiving and patient record management.
Versatile Connectivity Options
Multiple input/output ports including VGA, USB, and DICOM network connectivity for seamless integration with PACS systems, printers, and external storage devices.
Why Choose the NEUCU30 Ultrasound System
Superior Image Quality and Diagnostic Confidence: The NEUCU30 delivers exceptional image quality through advanced full-digital beam forming technology combined with proprietary imaging enhancements such as THI, PSHI TM broadband harmonic imaging, and iBeam TM intelligent space image technology. These sophisticated processing algorithms work together to provide crystal-clear images with superior tissue differentiation, reduced artifacts, and enhanced contrast resolution. The system’s real-time dynamic focusing and dynamic aperture capabilities ensure optimal image quality at all depths, giving clinicians the confidence they need for accurate diagnoses across a wide range of clinical applications.
Comprehensive Clinical Versatility: Designed to meet the diverse needs of modern medical imaging facilities, the NEUCU30 offers an extensive array of specialized measurement packages and imaging modes. From obstetric biometry and fetal assessment to cardiac evaluation, vascular studies, and small parts imaging, this system provides tailored solutions for every clinical specialty. The intelligent built-in workstation system includes pre-configured protocols for abdomen, gynecology, obstetrics, urology, cardiology, musculoskeletal, and vascular examinations, streamlining workflow and ensuring standardized, reproducible results. With support for multiple displaying modes including B, M, PW, duplex, triplex, and color flow mapping, the NEUCU30 adapts seamlessly to your clinical requirements.
Enhanced Workflow Efficiency: The NEUCU30 is engineered with workflow optimization in mind, featuring one-key image optimization for instant enhancement, automated measurement calculations with comprehensive reporting, and intuitive user interface design. The cine loop functionality with variable speed control allows for detailed retrospective analysis, while the 500G storage capacity ensures ample space for patient data archiving. Multiple connectivity options including USB ports, VGA output, and DICOM network capability facilitate seamless integration with existing hospital information systems and enable efficient data sharing. The ergonomic trolley design with free arm positioning and multiple probe connectors further enhances operational efficiency and user comfort during extended scanning sessions.
Exceptional Value and Reliability: The NEUCU30 represents an outstanding investment for healthcare facilities seeking advanced ultrasound capabilities without compromising on quality or functionality. The standard configuration includes dual probes (3.5MHz convex and 7.5MHz linear), a 15-inch LED monitor, and comprehensive documentation, providing everything needed to begin diagnostic imaging immediately. Optional accessories such as transvaginal probes, larger monitors, and DICOM 3.0 connectivity allow for system customization to meet specific clinical needs. Backed by Neuvar’s commitment to quality and supported by comprehensive technical support, the NEUCU30 delivers reliable performance and long-term value for medical imaging departments of all sizes.
Frequently Asked Questions
What imaging modes does the NEUCU30 support?
The NEUCU30 supports a comprehensive range of imaging modes including B-mode, B/B, 4B, B/M, M-mode, PW (Pulsed Wave Doppler), B/C, B/C/D, B/D, duplex, triplex, and color flow mapping (CFM). This versatility allows for complete diagnostic evaluation across all clinical applications, from basic anatomical imaging to advanced hemodynamic assessment.
What probes are included with the standard configuration?
The standard configuration of the NEUCU30 includes a 3.5MHz convex probe for abdominal and obstetric imaging, and a 7.5MHz linear probe for small parts, vascular, and musculoskeletal applications. The system accommodates up to 4 probe connectors, and optional probes such as a 6.5MHz transvaginal probe are available for expanded diagnostic capabilities.
What is the maximum scanning depth of the NEUCU30?
The NEUCU30 offers a scanning depth of up to 300mm, providing excellent penetration for imaging deep anatomical structures and accommodating patients of various body habitus. The system’s advanced signal processing ensures maintained image quality even at maximum depth.
Does the system include obstetric measurement packages?
Yes, the NEUCU30 includes comprehensive obstetric measurement packages with automated calculations for gestational age estimation. The system supports measurements including gestational sac (GS), biparietal diameter (BPD), crown-rump length (CRL), femur length (FL), yolk sac (YS), transverse abdominal diameter (TAD), left ventricle (LV), occipitofrontal diameter (OFD), nuchal translucency (NT), abdominal circumference (AC), head circumference (HC), anterior-posterior abdominal diameter (APAD), and cervical length. EDD (estimated due date) tables are integrated for convenient clinical reporting.
What connectivity options are available for data management?
The NEUCU30 features multiple connectivity options including USB ports for external storage devices, VGA output for external displays, and DICOM network port for integration with hospital PACS systems. The system supports image export in BMP, JPEG, and PNG formats and includes a DVD-RW drive for archiving. Optional DICOM 3.0 compatibility is available for enhanced network functionality.
Can the system perform cardiac measurements?
Yes, the NEUCU30 includes a comprehensive cardiac measurement package supporting heart rate calculations, valve velocity measurements, left ventricular assessment, aortic measurements, mitral valve evaluation, and ventricular function analysis. The M-mode and Doppler capabilities enable detailed hemodynamic assessment and cardiac function evaluation.
What image enhancement technologies are included?
The NEUCU30 incorporates multiple advanced image enhancement technologies including Tissue Harmonic Imaging (THI), PSHI TM broadband multi-frequency harmonic imaging, speckle reduction algorithms, iBeam TM intelligent space image technology, iZoom TM undistorted magnification, edge enhancement, smoothing functions, and one-key optimization. These technologies work together to deliver superior image quality with reduced artifacts and enhanced diagnostic detail.
Is the system suitable for vascular imaging?
Absolutely. The NEUCU30 is highly capable for vascular imaging applications, featuring color Doppler, spectral Doppler analysis, and specialized vascular measurement packages including stenosis assessment (diameter and area), left/right vertebral artery evaluation, and carotid artery measurements. The adjustable Doppler parameters including wall filter, baseline, sampling volume, and PRF allow for optimized vascular examination and precise hemodynamic evaluation.
