Basic Ophthalmic A/B Scan NEU2000BER
- Advanced Basic Ophthalmic A/B Scan NEU2000BER for precise eye measurements
- A-scan probe frequency: 10MHZ with ±0.5 MHZ error
- High precision measurement up to 0.05mm for ACD depth, lens, and axial length
- IOL calculation options: SRK/II, SRK/T, Holladay, SCDK, Hoffer-Q
- Dual operation modes: Automatic and Manual for versatile usage
- B-scan mode with mechanical sector scans for in-depth analysis
- 50mm detection depth and 53-degree scan angle for comprehensive imaging
- High-resolution imaging with vertical resolution of 0.5mm and lateral resolution of 1.0mm
- 256 gray scale display for detailed image representation
- Image post-processing features: brightness, contrast, smooth, sharp, stretch, and equalize
- SKU
- NEU2000BER
- Brand
- MedGroup
- Availability
- In stock
- ✓ Warranty included
- ✓ Worldwide shipping
Basic Ophthalmic A/B Scan NEU2000BER
Advanced dual-mode A/B scan system delivering precise biometric measurements and comprehensive intraocular imaging. Engineered for cataract surgery planning, retinal assessment, and IOL power calculations with high-resolution 256 gray-scale imaging and intuitive automatic or manual operation.
Clinical overview
The NEU2000BER is a dual-mode ophthalmic ultrasound system combining A-scan biometry with B-scan imaging in a single, integrated platform. The A-scan mode delivers high-precision measurements of axial length, anterior chamber depth, and lens thickness—critical parameters for accurate IOL power calculations. The B-scan mode provides real-time mechanical sector imaging for posterior segment assessment, particularly valuable in cases of dense cataracts or vitreous opacities where optical biometry is limited.
With 10 MHz probe frequency, ±0.05 mm measurement precision, and support for five major IOL calculation formulas (SRK/II, SRK/T, Holladay, SCDK, Hoffer-Q), the system streamlines preoperative planning and reduces calculation errors. The 256 gray-scale display, combined with post-processing tools (brightness, contrast, smooth, sharp, stretch, equalize), ensures diagnostic clarity in all clinical scenarios. Dual operation modes—automatic for routine cases and manual for complex anatomy—provide flexibility for diverse patient populations.
Key features & surgeon benefits
High-Precision Biometry
- ±0.05 mm measurement precision for axial length, ACD, and lens thickness
- 10 MHz probe frequency with ±0.5 MHz error tolerance
- Automatic and manual operation modes for flexible measurement protocols
Five Formula Options
- SRK/II, SRK/T, Holladay, SCDK, and Hoffer-Q formulas
- Built-in IOL table for rapid power selection
- Mass memory storage for case data and patient records
Comprehensive B-Scan
- Mechanical sector scans with 53° scan angle and 50 mm detection depth
- 0.5 mm vertical and 1.0 mm lateral resolution for detailed imaging
- 256 gray-scale display with 10-frame storage capacity
Clinician-Friendly Design
- Image post-processing: brightness, contrast, smooth, sharp, stretch, equalize
- External high-definition ink-jet printer support for reports
- Intuitive interface for rapid measurement and documentation
Technical specifications
| Indications | Cataract surgery planning, axial length measurement, anterior chamber depth assessment, lens thickness evaluation, retinal imaging, IOL power calculation |
|---|---|
| A-Scan Probe Frequency | 10 MHz (±0.5 MHz error) |
| A-Scan Precision | 0.05 mm |
| A-Scan Measurement Parameters | ACD depth, lens thickness, axial length, average values |
| IOL Calculation Formulas | SRK/II, SRK/T, Holladay, SCDK, Hoffer-Q |
| A-Scan Operation Modes | Automatic, Manual |
| B-Scan Mode | Mechanical sector scans |
| B-Scan Angle | 53° |
| B-Scan Detection Depth | 50 mm |
| B-Scan Probe Frequency | 10 MHz (±0.5 MHz error) |
| B-Scan Vertical Resolution | 0.5 mm |
| B-Scan Lateral Resolution | 1.0 mm |
| Gray Scale Display | 256 levels |
| Display Modes | B; B+B; B+A |
| Image Storage | 10 frames |
| Image Post-Processing | Brightness, contrast, smooth, sharp, stretch, equalize |
| Data Storage | Mass memory with built-in case data |
| Output | External high-definition ink-jet printer support |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Main Console Unit | A/B scan processor with integrated display and controls | 1 |
| A-Scan Probe | 10 MHz transducer with cable assembly | 1 |
| B-Scan Probe | 10 MHz mechanical sector transducer with cable assembly | 1 |
| Probe Holder | Adjustable stand for probe positioning | 1 |
| Power Supply | AC adapter with regional plug options | 1 |
| User Manual | Comprehensive operating and maintenance guide | 1 |
| Calibration Block | Reference standard for system verification | 1 |
