MEK-T6
- Advanced MEK-T6 ultrasound device with multiple probe options
- Supports convex, linear, trans-vaginal, phased array, micro convex, and 4D volume probes
- Two-dimensional imaging with adjustable gain, TGC, and dynamic range
- Enhanced color imaging mode with 8 frequency conversions and adjustable color mapping
- Spectrum Doppler mode for real-time data analysis and various speed scales
- Comprehensive measurement and analysis functions for obstetrics and gynecology
- Built-in ≥128G solid-state hard disk for fast and stable operation
- User-friendly graphic and text management system for patient data organization
- Multiple interfaces including USB, VGA, RJ-45, and VIDEO for connectivity
- Equipped with a robust software package for diverse medical applications
- SKU
- MEK-T6
- Brand
- Meditech
- Availability
- In stock
- ✓ Warranty included
- ✓ Worldwide shipping
MEK-T6
Advanced multi-probe ultrasound diagnostic system with comprehensive 2D, color Doppler, and spectrum analysis capabilities. Designed for obstetrics, gynecology, and general abdominal imaging with professional-grade measurement and reporting tools.
Clinical overview
The MEK-T6 is a professional-grade ultrasound diagnostic system engineered for comprehensive imaging across obstetrics, gynecology, abdominal, cardiac, and vascular applications. With support for six interchangeable probe types and advanced imaging modes, the system delivers high-resolution diagnostic data suitable for routine screening, detailed anatomical assessment, and hemodynamic analysis.
The integrated solid-state hard disk (≥128 GB) ensures rapid system startup and stable operation, while the comprehensive graphic and text management system streamlines patient data organization, report generation, and archival. Multiple connectivity interfaces (USB, VGA, RJ-45, VIDEO) facilitate seamless integration into existing clinical workflows and PACS environments.
Key features & surgeon benefits
Multi-Probe Versatility
- Six probe types: convex, linear, trans-vaginal, phased array, micro convex, and 4D volume
- Frequency range 2.0–10.0 MHz for optimal penetration and resolution
- Seamless probe switching for comprehensive diagnostic coverage
Advanced Processing
- Adjustable gain (0–100), TGC (8 segments), and dynamic range (20–280 dB)
- 12 false color palettes and 8 smoothing levels for optimized visualization
- Up to 6 focal points with real-time adjustment throughout imaging
Hemodynamic Assessment
- Spectrum Doppler with automatic and manual envelope detection
- Real-time calculation of PSV, EDV, RI, PI, S/D, ACC, and HR
- Adjustable speed scales (3–2288 cm/s) and angle correction (±80°)
Integrated Reporting
- 16 report templates for rapid documentation
- One-key fast report generation with customizable measurement overlays
- 1200-frame movie playback for dynamic review and archival
Technical specifications
| Indications | Obstetrics, gynecology, abdominal, cardiac, vascular, urology, orthopedics, peripheral vessels, small organs, carotid artery |
|---|---|
| Probe types | Convex array, linear array, trans-vaginal, phased array, micro convex, 4D volume |
| Frequency range | 2.0–10.0 MHz (probe-dependent) |
| Display depth | 20 mm to >317 mm (cardiac probe up to 371 mm) |
| Scan line density | >256 lines (visually tunable) |
| Color frequency conversions | 8 frequency options with adjustable mapping |
| Spectrum Doppler speed scale | 3–2288 cm/s (visually adjustable) |
| Storage | ≥128 GB solid-state hard disk |
| Movie playback | 1200 frames |
| Interfaces | 6× USB, 1× VGA, 1× RJ-45, 1× VIDEO, 1× grounding wire |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Main console | MEK-T6 ultrasound system with integrated ≥128 GB SSD | 1 |
| Convex array probe | 2.5–6.0 MHz frequency options | 1 |
| Linear array probe | 6.0–10.0 MHz frequency options | 1 |
| Trans-vaginal probe | 4.5–9.0 MHz frequency options | 1 |
| Phased array probe | 2.5–4.0 MHz frequency options | 1 |
| Micro convex probe | 4.5–9.0 MHz frequency options | 1 |
| 4D volume probe | 2.0–6.0 MHz frequency options | 1 |
| Professional software package | Abdomen, volume, ratio, obstetrics, gynecology, small organs, carotid, urology, orthopedics, peripheral vessels | 1 |
| Connectivity cables | USB, VGA, RJ-45, VIDEO, grounding wire | As applicable |
Get in touch for pricing & availability
Contact our sales team to discuss system configuration, probe options, and volume pricing. We provide comprehensive support, training, and customization to meet your facility's diagnostic imaging requirements.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
Customer reviews
No reviews yet — be the first to share your experience.
