Portable Sterilizer NEUPS29
- Portable Sterilizer NEUPS29 with advanced sterilization technology
- Sterilizing chamber volume options: 20L, 24L, 35L, 50L
- Efficient working pressure of 0.22Mpa ensures effective sterilization
- Operates at a high temperature of 134℃ for thorough cleaning
- Adjustable temperature range from 105℃ to 134℃
- Convenient timer setting from 0 to 60 minutes for precise control
- Heat average maintained within ± 1℃ for consistent results
- Power specifications: 2.7 KW / AC220V 50Hz
- Compact dimensions: Up to 770×600×540 mm for space-saving use
- Lightweight design with a maximum weight of 105 kg for easy transport
- Includes multiple sterilizing plates to accommodate various instruments
- SKU
- NEUPS29
- Brand
- MedGroup
- Availability
- In stock
- ✓ Warranty included
- ✓ Worldwide shipping
Portable Sterilizer NEUPS29
Advanced portable sterilization system engineered for clinical and laboratory environments. Features multiple chamber volume options, precise temperature control, and efficient steam sterilization at 134°C with working pressure of 0.22 MPa. Compact, lightweight design ensures easy transport and installation in diverse healthcare settings.
Clinical overview
The Portable Sterilizer NEUPS29 delivers reliable steam sterilization for surgical instruments, laboratory equipment, and medical devices in clinical and hospital environments. With chamber volumes ranging from 20L to 50L, this system accommodates diverse sterilization loads while maintaining consistent temperature control and pressure management. The adjustable temperature range (105–134°C) and programmable timer (0–60 minutes) enable precise sterilization protocols tailored to specific instrument types and material compositions.
Engineered for portability and efficiency, the NEUPS29 combines compact dimensions (up to 770×600×540 mm) with robust construction, making it suitable for operating rooms, central sterile processing departments, dental clinics, and research laboratories. The heat uniformity of ±1°C ensures reproducible sterilization outcomes, while the 2.7 kW power specification and AC110V/220V 50/60Hz operation integrate seamlessly into standard clinical infrastructure.
Key features & surgeon benefits
Flexible Chamber Volumes
- Four chamber size options: 20L, 24L, 35L, 50L
- Accommodates varying instrument loads and batch sizes
- Sterilizing plates included: 400×200×30 mm (4 pieces) or 500×250×30 mm (4 pieces)
Precise Temperature Control
- Working temperature: 134°C for rapid, effective sterilization
- Adjustable range: 105–134°C for material-specific protocols
- Heat uniformity: ±1°C ensures consistent results across all loads
Programmable Operation
- Timer setting: 0–60 minutes for precise cycle control
- Working pressure: 0.22 MPa for optimal steam penetration
- Compact footprint reduces space requirements in clinical settings
Lightweight, Mobile Design
- Maximum weight: 105 kg for easy transport and repositioning
- Dimensions up to 770×600×540 mm fit standard clinical spaces
- Ideal for multi-department facilities and mobile surgical units
Technical specifications
| Indications | Sterilization of surgical instruments, laboratory equipment, and medical devices |
|---|---|
| Chamber volumes | 20L, 24L, 35L, 50L |
| Working pressure | 0.22 MPa |
| Working temperature | 134°C |
| Temperature adjustment range | 105–134°C |
| Timer range | 0–60 minutes |
| Heat uniformity | ±1°C |
| Power specification | 2.7 kW / AC110V/220V 50/60Hz |
| Dimensions (max) | 770×600×540 mm |
| Weight (max) | 105 kg (gross); 86 kg (net) |
| Sterilizing plates | 400×200×30 mm (4 pieces) or 500×250×30 mm (4 pieces) |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Sterilizing chamber | Stainless steel chamber (35L or 50L option) | 1 |
| Sterilizing plates | 400×200×30 mm (35L) or 500×250×30 mm (50L) | 4 |
| Control panel | Temperature and timer controls with display | 1 |
| Safety valve | Pressure relief and safety mechanism | 1 |
| Power cord | AC110V/220V 50/60Hz connection cable | 1 |
Get in touch for pricing & availability
Contact our sales team to discuss chamber volume options, customization requirements, and delivery timelines for the Portable Sterilizer NEUPS29. We provide comprehensive support and technical guidance for clinical implementation.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
