Colposcope Video Machine for Gynaecology NEUCE06
- High-resolution CCD camera with 550 TV lines for clear imaging.
- Fast auto-focus and manual focus control for optimal precision.
- Adjustable LED light source with customizable brightness settings.
- Integrated computer imaging for data management and analysis.
- Supports multiple languages including English, Spanish, and Russian.
- Unique foot switch for easy picture capturing during examinations.
- Adjustable vertical stand for convenient height settings.
- Real-time dynamic images observable on an optional 2.5” LCD screen.
- Includes a standard case report template for easy editing and printing.
- Stores abundant image data for enhanced diagnostic capabilities.
- SKU
- NEUCE06
- Brand
- MedGroup
- Availability
- In stock
- ✓ Warranty included
- ✓ Worldwide shipping
Colposcope Video Machine for Gynaecology NEUCE06
Professional-grade colposcope system with high-resolution CCD imaging, integrated computer analysis, and real-time visualization. Designed for comprehensive cervical examination with advanced diagnostic capabilities and intuitive workflow control.
Clinical overview
The NEUCE06 is a comprehensive colposcope video system engineered for precise cervical examination and diagnosis. Featuring a 1/4" high-resolution CCD camera with 550 TV lines, the system delivers exceptional image clarity essential for identifying subtle pathological changes. The integrated computer imaging platform enables real-time analysis, case documentation, and long-term image archiving for enhanced diagnostic confidence and clinical continuity.
With multi-language support (English, Spanish, Russian, Vietnamese, and Chinese), adjustable LED illumination, and intuitive foot-switch control, the NEUCE06 streamlines the colposcopy workflow while maintaining the precision required for accurate tissue assessment and treatment planning.
Key features & surgeon benefits
High-Resolution CCD Optics
- 1/4" high-resolution colorful digital CCD camera with 550 TV lines
- 470-line axial resolution with 50dB signal-to-noise ratio
- Fast auto-focus and manual focus control for optimal precision
- 1–128× zoom range for detailed tissue examination
Intuitive Control & Positioning
- Unique foot switch for hands-free image capture during examination
- Adjustable vertical stand with freely lockable height settings
- Control handle for focal length, zoom, white balance, and brightness adjustment
- Real-time dynamic image observation on optional 2.5" LCD screen
Integrated Computer Imaging & Analysis
- Comprehensive case report template with true-color image integration
- Storage capacity for abundant diagnostic image data
- Timing function for acetic acid and iodine reaction tests
- 175-image diagnostic database for reference and comparison
- Case search, backup, and printing functionality
Advanced LED Light Source
- Adjustable super-cold LED light source for consistent, flicker-free illumination
- Customizable brightness settings for optimal tissue visualization
- White balance auto-adjustment for true-color image reproduction
- Reduced thermal load for patient comfort
Technical specifications
| Model | NEUCE06 |
|---|---|
| Indications | Cervical examination, colposcopy, tissue imaging and diagnosis |
| Camera | 1/4" high-resolution colorful digital CCD camera |
| Resolution | 550 TV lines; 470-line axial resolution |
| Signal-to-Noise Ratio | 50dB |
| Focus Distance | Standard 100–400mm; supported range 10–1000mm |
| Scan Range | 2.5mm–20mm–320mm |
| Depth of Field | 15mm–40mm (standard); 15mm–480mm (extended) |
| Zoom Range | 1–128× |
| Focus Control | Auto-focus (AF) and manual focus (MF) |
| Light Source | Adjustable LED with brightness control |
| Output Interfaces | Video, S-video, PAL |
| Video Output Standard | PAL, VBS-standard 1.0Vp-p |
| Power Requirements | AC 110V/220V ±10% |
| Configuration | Complete system with trolley |
| Languages Supported | English, Spanish, Russian, Vietnamese, Chinese |
| Optional Accessories | 2.5" LCD screen for real-time monitoring |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Colposcope Head | 1/4" CCD camera with 550 TV lines, auto/manual focus, LED illumination | 1 |
| Control Handle | Multi-function handle for zoom, focus, brightness, white balance, and image freeze | 1 |
| Foot Switch | Hands-free image capture control | 1 |
| Vertical Stand | Adjustable height stand with locking mechanism and trolley base | 1 |
| LED Light Source Unit | Adjustable super-cold LED illumination with brightness control | 1 |
| Computer Imaging Module | Integrated system for image capture, storage, analysis, and case report generation | 1 |
| Video Output Cables | Video, S-video, and PAL connectors | 1 set |
| Case Report Template | Pre-configured template for diagnosis documentation and printing | Included |
| Diagnostic Image Database | 175 reference images for clinical comparison | Included |
| Optional LCD Screen | 2.5" display for real-time image monitoring (optional accessory) | Optional |
Get in touch for pricing & availability
Contact our sales team to discuss system configuration, pricing, and delivery timelines. We offer comprehensive support, training, and customisation options to meet your clinical requirements.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
